Different Parameters, Different Price. Price Reference Only.
The low bed trailer loading ramps are made by high strength steel, TITAN has different types of ramps: mechanical ramp and hydraulic ramp.
Low Bed Trailer is widely used, mainly for medium and long-distance freight transportation. Low bed trailers are commonly used to transport heavy vehicles, rail vehicles, mining machinery, forestry machinery, agricultural machinery, and other heavy-duty cargo.
The low bed trailer loading ramps are made by high strength steel, with high loading capacity, which will not happen to the deformation when carrying heavy equipment. There are two types of ramps: mechanical ramp and hydraulic ramp.
Heavy Duty 4 line 8 axle Low Bed Trailer Price
Overall dimension: 19000mm * 3350mm *3400mm
Loading capacity(T): 150T
Axle: 4 Line 8 Axle
Rim: 8.0-20
Tire: 11.00R20
Suspension: Mechanical suspension
Spring leaf: 90(W)mmx13(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Landing gear: JOST brand
Main beam: Height: 500mm, Upper plate: 20mm, Middle plate: 12mm, Lower plate: 20mm, Material: Q345B steel.
Bottom Platform: 5mm thick checkered plate
Ramp: Spring ramp
Gooseneck: Optional
ABS: Optional
Valve: WABCO valve
Light: LED light (specially intended for oversea markets)
120 Ton Low Bed Trailer Truck details display video
Through this videos, you can learn about different types of lowbed semi-trailers, as well as the process, testing, packaging and customer feedback, etc.
